Water Management
Heavy-duty submersible pump for drainage and wastewater.
Permanent-magnet variable-frequency control
Handles domestic sewage with limited sand and gravel
Constant-pressure operation
Low-energy and low-noise design
Product overview
Maximum values transcribed from the supplied brochure or product sheet, including confirmed shared-platform data where identified. Select a pump from its full performance curve and site conditions, not from maximum values alone.
| Model | Max input power | Max head | Max flow |
|---|---|---|---|
| 50SX-8-6-370AT | 370 W | 10 m | 14.0 m³/h(233 L/min) |
| 50SX-10-7-550AT | 550 W | 14 m | 17.0 m³/h(283 L/min) |
| 50SX-12-8-750AT | 750 W | 15 m | 18.0 m³/h(300 L/min) |
| 50SX-12-12-1100AT | 1100 W | 20 m | 21.0 m³/h(350 L/min) |
| 50SX-16-12-1500AT | 1500 W | 21 m | 23.0 m³/h(383 L/min) |
| 40SX-5-7-370AG | 370 W | 13 m | 10.0 m³/h(167 L/min) |
| 40SX-6-8-550AG | 550 W | 16 m | 11.0 m³/h(183 L/min) |
| 40SX-6-9-750AG | 750 W | 18 m | 12.0 m³/h(200 L/min) |
| 40SX-8-13-1100AG | 1100 W | 26 m | 13.0 m³/h(217 L/min) |
| 40SX-8-14-1500AG | 1500 W | 28 m | 14.0 m³/h(233 L/min) |
Share your required flow, pressure, water source and installation location with our team. We can review model selection and provide a quotation for your application.
